Pulsed Erbium-doped Fiber Amplifier for C-band is a series of fiber amplifier products dedicated to picosecond and nanosecond laser pulses. It outputs high peak power laser pulses while minimizing fiber nonlinear effects. It has the advantages of high gain and low noise. Supports PC software control, compact size and easy integration, and can provide desktop or modular packaging.

Features Applications
·        Short pulse amplification

·        High peak power

·        Customizable

 ·        Fiber sensing

·        Fiber Lidar

·        Fiber laser
Performance Specifications

Optical Parameter Unit Typical Values Remark
Wavelength Range nm 1530~1565nm *Optional bandpass filter
Pulse Width ns 0.1~50
Pulse frequency kHz 1~1000
Input pulse peak mW 1~10
output Peak pulse W 1~1000
Noise Figure dB 5.5
Gain Flatness dB 3
Polarization Dependent Gain dB <0.5
Polarization Mode Dispersion ps <0.5
Input/output Isolation dB >35
Fiber Type – SMF-28 1.0m length
Optical Connector – FC/APC
Control Mode – Automatic current control (ACC) *Note 1



Electrical and environmental parameters Desktop Module
Control Mode Button RS232
Communication Interface * Optional DB9 Female
Power Supply 100~240V AC, <30W 5V DC, <15W
Dimensions 260(W)×280(D)×120(H)mm 125(W)×150(D)×20(H)mm
Operation Temperature Range -5~+55°C
Operation Humidity Range 0~70%

Ordering Information P/N: ①-②-③-④-⑤-⑥

When you inquire, please provide the correct P/N number according to our ordering information, and attach the appropriate description would be better.

① ② ③ ④ ⑤ ⑥
EDFA Operation Wavelength Amplifier type Output pulse peak power (W) Fiber Type Package Type
  C: C-band PL: pulse amplifier 100/200/500/1000 SM: SMF-28e M: Module

B: Desktop
